12 Volt Diesel Pump (40lpm)

12 Volt Diesel Pump (40lpm) Specifications

Height (mm) no

specification

Cast iron pump body finished with anti-corrosion paint
Vane pump with sintered steel rotor and acetal resin vanes
By-pass valve incorporated in the pump body
Direct current brush motor with permanent magnet stator
Motor protection grade IP55
Used in intermittent service with 30-minute work cycles
Pump attachment support bracket
Integrated on/off switch.
Flanged 1″ connectors
Available with power cables, incorporated fuses and pincers for connection to terminal strips

Technical Features

Self-priming diesel fuel transfer pumps
Sintered steel rotor & acetal resin vanes
Cast iron pump body with anti-corrosion paint
Incorporated bypass valve & NBR lip seal
Flow rate: 50ltr per Min
On/off switch
Cable and clips (2 and 4m options)
Direct current brush motor with permanent magnet stator
30min duty cycle
Thermal motor overload protection
Hose barb inlet/outlet ports
Available with horizontal or vertical ports
Carry handle
Protection Grade: IP55
Available in 12v/24v

The new BP3000 DC pump has been designed to satisfy requirements for a safe and reliable way of transferring diesel throughout various applications from battery power when no mains electrical supply is available. Its compact size makes it easily portable and it is supplied with a carry handle as standard.

This pump has been designed and manufactured to a high specification to create a unique new product. The pump has the flexibility to be mounted in various positions and has a range of optional accessories allowing a number of connection configurations.

Incorporating a strong DC brush motor this gives the pump flow capabilities of up to 50l/min, whilst tolerating the back pressure the installation may incur.
